Grainiac

Grainiac is a granular sampler. It currently runs as a vst3 plugin, standlone with a tui and a vst3 plugin with a tui style interface which is currently experimental and under development.

Project Structure

Config

You need a config.json file under ~/.config/grainiac/ with the following schema:

{
  "presets": [
    {
      "gain": [0.5, 0.5, 0.5, 0.5],
      "loop_start": [0.25, 0.25, 0.25, 0.25],
      "loop_length": [0.5, 0.5, 0.5, 0.5],
      "density": [0.5, 0.5, 0.5, 0.5],
      "grain_length": [0.5, 0.5, 0.5, 0.5],
      "play_speed": [1.0, 1.0, 1.0, 1.0],
      "spray": [0.1, 0.1, 0.1, 0.1],
      "pan": [0.0, 0.0, 0.0, 0.0],
      "spread": [1.0, 1.0, 1.0, 1.0],
      "attack": [0.25, 0.25, 0.25, 0.25],
      "release": [0.25, 0.25, 0.25, 0.25],
      "pitch": [1, 1, 1, 1],
      "play_dir": [0, 0, 0, 0],
      "grain_dir": [0, 0, 0, 0],
      "mode": [0, 0, 0, 0],
      "name": "preset_1",
      "char": "1"
    }
  ],
  "mapping": {
    "loop_start": 40,
    "loop_length": 41,
    "density": 42,
    "grain_length": 43,
    "play_speed": 44,
    "spray": 45,
    "pan": 46,
    "spread": 47,
    "attack": 48,
    "release": 49,
    "pitch": 50,
    "gain": 51,
    "record": 52,
    "hold": 53,
    "play_dir": 54,
    "grain_dir": 55,
    "mode": 56
  }
}

The arrays under presets represent tracks A to D. The char field is the key to press to load the preset. The name field is currently unused.

The mapping section maps MIDI CC numbers to parameters. Each track corresponds to a MIDI channel (channel 1 = track A, channel 2 = track B, etc.).

To save and load audio files, manually create the folder ~/.local/share/grainiac/.

Key Mappings
